DECWARE Zen Triode Amplifier
Model SE84B
KIT ASSEMBLY INSTRUCTIONS
(C)1998 by High Fidelity Engineering Co.

Building your very own Zen Triode Amp with expert results is now a reality thanks to the technology of our web cam!

We're going to crawl you through the insides of a Zen like "Honey I shrunk the kids" and give you a clear picture of the assembly process!

Your Zen Triode Kit comes with everything needed to completely assemble and listen to your new amp. All you will need is solder, a small amount of hookup wire and these invaluable web instructions. Everything else is supplied in your Kit.



WARNING

This kit contains no circuit boards, requires the ability to read and understand schematics, as well as solder in tight places. This is NOT a good project for the novice kit builder, but is offered for those who already have experience building amplifiers.


If you've read the reviews about this fine amplifier and think those people find the experience satisfying imagine how it will feel to listen to the magic come from an amplifier built with your own hands!

LET'S BEGIN

To build your Zen amp correctly, understand at the time of this article I have personally hand built over 100 of these, and almost 20 prototypes before that.

I learned an interesting thing about building amps during this process and it was simply that small things make a big difference.

Even though after 20 prototypes I thought the amp was perfect, I found subtle ways to improve the parts layout over the course of building the first 50 units and realized that there is no way someone could build a single prototype of any amplifier regardless of his or her skill and judge the resulting sound to be representative of that circuit.

All these variations I went through can be broken down into three main things:

The first is parts values, the second is part brands, and the third is the topology of the parts and how it effects the soldering and single path length. Even if you take a simple circuit like this Zen amp and start trying all combinations of these three things, you will find the number of combinations to be huge. Interesting thing,... in an amplifier this pure, each of these combinations yields a detectable change to the sonic signature and or performance of the amplifier.

So with that rather long winded introduction you can feel comfortable that you will be able to build an amplifier that is finely evolved work of art.

Here in these online pictorial instructions, you will learn exactly how to layout and build a Zen Triode amplifier just like we do, so that when you take the bottom off and look inside you truly will have a masterpiece.

THE FOLLOWING PAGES CONTAIN THE STEP-BY-STEP INSTRUCTIONS AND PICTURES OF HOW TO BUILD A DECWARE ZEN TRIODE AMPLIFIER.

STEP 1 - READ THIS PAGE

and then press here to start
