Steve's BIG BETSY Project (Read 56686 times)
Palomino
Seasoned Member
****




Posts: 2037
Re: Steve's BIG BETSY Project
Reply #600 - 08/21/19 at 17:02:11

Last night, I played around with the sub and super tweeter.  Some help on both ends.  Overall, the sub impact was bigger than the ST from just what I heard.  Interesting how the ST has an impact below 10Khz.  1/24th octave smoothing.

I don't know what that dip at 40hz is about.  I'll play with phase.

Back to top



i7 Mac Mini with LPSU/SSD running Audirvana 3.2, Uptone Audio Regen on LPSU, TEAC UD503, Decware Silver ICs, 25th Anniversary Zen, PS Audio P5 Power Supply, PS Audio Power Cords, Vintage Western Electric 16g Speaker wires, DIY Open Baffle Speakers
  IP Logged
Geno
Seasoned Member
****


Without music, life
would be a mistake.
Nietzsche

Posts: 529
Re: Steve's BIG BETSY Project
Reply #601 - 08/21/19 at 19:41:34

Nice Archie! Much nicer than than the sandbags I plan on using Embarrassed
