1  AUDIO FORUMS / D.I.Y. / Re: Taking a shot at building the ZKIT1
 on: Today at 11:49:28
Started by martin | Post by Core32
Martin,
I'll take a look at your wiring later today. Just heading off to work here.
I don't know about the board for CKC but if you look at the schematic section I posted for you (mine), C9 and C10 are the Hazen grid mods.
And at the moment I can't remember what the CKC mod consisted of.
If it's the input tube bias switch then no I do not think it's in the board.

2  AUDIO FORUMS / DECFEST / Re: DECFEST 2016 !!!
 on: Today at 10:01:42
Started by martin | Post by Jeff of Arabica
me too

3  AUDIO FORUMS / D.I.Y. / Re: Taking a shot at building the ZKIT1
 on: Today at 08:54:57
Started by martin | Post by martin
Two more questions: What do I do with the chassis ground hook-up?

Is the CKC mod already built in to the board?

Thanks!

4  AUDIO FORUMS / D.I.Y. / Re: Concrete Block speakers
 on: Today at 06:11:59
Started by Donnie | Post by Lonely Raven

Nifty idea, except isn't a cinder block porous?




5  AUDIO FORUMS / D.I.Y. / Re: Latest OB baffle build
 on: Today at 06:07:31
Started by Palomino | Post by Lonely Raven

Hey, we're only 3 hours away.  ;)

6  AUDIO FORUMS / DECFEST / Re: DECFEST 2016 !!!
 on: Today at 06:01:48
Started by martin | Post by martin
Since I missed this one I'm hoping I'll make it in 2017.   Cry

7  AUDIO FORUMS / D.I.Y. / Re: Taking a shot at building the ZKIT1
 on: Today at 05:55:09
Started by martin | Post by martin


This is a closer pic to try and be sure things are shown clearly.  If I need to post any more pics or information, please let me know!

Thanks much for any help I get!

8  AUDIO FORUMS / D.I.Y. / Re: Taking a shot at building the ZKIT1
 on: Today at 05:52:02
Started by martin | Post by martin


This shows how I hooked both black leads from the power transformer to the IEC plug (at almost the exact middle of the pic on my screen).  One of the two black leads goes directly to the "L" pin (load?) and then jumps to pin 1 on the LED rocker switch.  The ground pin on the IEC plug is attached to the case with a washer and screw.  The "N" pin (neutral?) has the white 110v LEDs attached.

On the switch pin 2 has the second black lead from the power transformer attached.  Pin 3 has the black leads from the LEDs (to light the tubes) attached.

The capacitor in the upper left of the pic is installed in what might be a unique way, but I needed it moved a bit to allow room for the IEC plug.

9  AUDIO FORUMS / D.I.Y. / Re: Taking a shot at building the ZKIT1
 on: Today at 05:31:46
Started by martin | Post by martin


This is a general shot of the Amp.

10  AUDIO FORUMS / General Discussion and Support / Re: Secret Decware Speaker Offering Coming Soon....
 on: Today at 05:21:43
Started by Steve Deckert | Post by Steve Deckert
I sent out the link to people on the list tonight so they can get their orders in and secure their place on the list.

Thanks,

Steve
